Strata 520/550/580Tender

Strata 520/550/580 Tender

We build lightweight, durable tenders that outperform anything in their class. Designed and crafted in New Zealand, every Smuggler tender is engineered for pure exhilaration and refined with thoughtful detail.No matter the purpose, size, layout, or drive system, we’ll integrate every element into a bespoke vessel that delivers exceptional performance and harmonises seamlessly with your yacht.

Tailor your tender to your exact needs with a range of console options and thoughtful standard features — including lifting rings for easy handling. And with our fully customisable range, you can choose your colours, layout, and finishes to create a vessel that’s truly your own. Browse our models to see how other owners have brought their custom Smuggler’s to life. Whether it’s a perfect fit for your tenderwell or a bespoke setup for your garage, we’ll craft a solution that works seamlessly for you. All of our recreational boats and amphibious boats can also be modified to be tenders if there is something more appealing in those ranges.

The Smuggler Strata 520 / 550 / 580 RIB Tenders are unrivalled in performance and quality. They have a 23 degree deep vee hull so the ride is comfortable and safe, no matter what the conditions. These tenders come with a range of console options to suit your needs, with lifting rings in the standard feature list. The beauty of the Smuggler Strata 5 metre range is our ability to custom finish your colours, console options and layout. Check out the gallery below of a few tenders we have made in this range. We can make your tender fit existing tenderwell or garage space. Get in touch with your requirements to see what we can do for you.

Quality no compromise.

HP Range 40 – 90 hp
Fuel Capacity 60 – 100 lt
Length 5.2-5.8m
Maximum Persons 5 – 7

SPECIFICATONS

HP Range
40 – 90 hp
Length overall (metres)
5.2 - 5.8m
Beam overall
2.4 metres
Beam internal
1.3 metres
Height overall
1.4 metres (can be lower)
Deadrise at transom
23 degrees
Weight
430 – 650 kg
Fuel capacity
60 – 100 lt
Max persons
5 – 7
Download Brochure

Standard Features

Structural

  • Fibreglass hull and liner
  • Fibreglass console
  • Helm seat for two with reversible back rest
  • PVC tubes, 5x chambers, safety handles inside, double wear patches where required, repair kit, dual action pump
  • Low profile fairlead on fibreglass support (if required)
  • Built in 70 litre fuel tank
  • Raised anchor locker with upholstered seat
  • Brass keel strip
  • Lifting rings x4
  • Towing eye

Engineering / Plumbing

  • Hydraulic steering
  • S/S fuel filler
  • Bilge pump

Electrical / Electronics

  • Switch panel
  • Navigation lights
  • Battery, box, switch gear

Upholstery / Miscellaneous

  • UV resistant upholstery
  • Side handles on console
  • Removable ski pole
  • Smuggler Graphics

Optional Features

Optional Features:

  • Outboard options from 40-90hp – All major brands fitted
  • Hypalon or TPU tubes upgrade
  • Console with chilly bin forward seat
  • Folding windscreen with s/s handrail
  • Dek King or Ultralon flooring fitted
  • VHF
  • 12v Outlet
  • Anchor, chain and warp
  • Transom mounted ski arch with 6 rod holders
  • Extra rod holder with bait board
  • Railblaza fittings
  • Folding canvas Bimini
  • Console cover
  • Fitted Storage cover
  • Tender name on tubes
  • Engine – All major outboard brands 40 – 90hp

Other Options available, please enquire
